73111SG010 Car Air Conditioning Compressor For Subaru lmpreza Forester WXSB012

Product Description

73111SG010 Car Air Conditioning Compressor For Subaru lmpreza For Forester WXSB012



The automobile air conditioning compressor is the core component of the automobile air conditioning system. It achieves rapid cooling of the air in the car by compressing low-pressure cold gas into high-pressure and high-temperature gas. Our compressors have the advantages of efficient refrigeration capacity, low energy consumption, low noise and reliability, providing drivers with a comfortable driving experience. We are committed to providing customers with high-quality, high-performance automotive air conditioning compressors and contributing to the comfortable driving experience in the automotive industry.





Parameter:



Model Number	WXSB012
Car Model	For Subaru lmpreza/Forester
Type	Ac Compressor
Year Model	N/A
Compressor type	DKV10R
OE No	73111SG010/T43562AA/T43563AA













Qualification Certificate







Common problems with automobile air conditioning compressors:



1. Refrigerant leaks: Over time, the refrigerant in the AC system can develop leaks, resulting in reduced cooling performance and potential damage to other components.



2. Compressor problems: The compressor is responsible for circulating the refrigerant and is prone to wear and tear. Common issues include compressor failure, clutch problems, or leaks.



3. Blower motor malfunction: The blower motor blows air into the cabin. If the motor fails or malfunctions, it can lead to weak airflow or no airflow at all.



4. Condenser troubles: The condenser, located at the front of the vehicle, can be damaged by debris, rocks, or accidents. A damaged condenser may reduce cooling efficiency.



5. Electrical issues: Problems with electrical components such as faulty wiring, blown fuses, or malfunctioning switches can affect the AC system's operation.



6. Blocked or clogged vents: Accumulated dust, debris, or objects obstructing the vents can restrict airflow and decrease the AC system's cooling capacity.



7.Expansion valve or evaporator problems: Issues with the expansion valve or evaporator, such as clogs or leaks, can lead to improper cooling and inadequate temperature regulation.













Piston-Type Compressors







The automotive air conditioning compressor is a crucial component of the AC system, responsible for compressing and circulating the refrigerant. It consists of several key parts that work together to achieve effective cooling.





1. Compressor Housing: The outer shell of the compressor, designed to enclose and protect the internal components.







2. Compressor Pulley: A pulley attached to the front of the compressor, connected to the engine via a belt. It transfers power from the engine to drive the compressor.







3. Clutch Assembly: The clutch allows the compressor to engage and disengage as required. It consists of an electromagnetic coil, friction plates, and a hub.







4. Swash Plate: This component converts the rotational motion of the compressor shaft into a reciprocating or up-and-down motion. It is responsible for compressing the refrigerant.







5. Piston: Linked to the swash plate, the piston moves up and down within the compressor cylinder to compress the refrigerant gas.







6. Reed Valves: These one-way valves control the flow of refrigerant into and out of the cylinder. They prevent backflow and ensure efficient compression.







7. Oil Separator: Located within the compressor housing, it separates the refrigerant oil from the refrigerant gas before it leaves the compressor.







8. Shaft Seal: This seal prevents refrigerant from leaking out and contaminants from entering the compressor. It ensures the integrity of the system.







9. Control Valve: Some compressors have a control valve that regulates the flow of refrigerant based on the cooling demands of the vehicle.







10. Mounting Brackets: These brackets secure the compressor to the engine or chassis, keeping it stable and in the correct position.







Each of these components plays a crucial role in the operation of the automotive air conditioning compressor. Their proper functioning ensures efficient cooling and overall performance of the AC system in vehicles.
