10PA17L 6PK Auto AC Compressor For Hyundai SantaFe 2.0 WXHY042

Product Description

10PA17L 6PK Auto AC Compressor For Hyundai SantaFe 2.0 WXHY042

Technical Information

What you need to know

If you’re replacing an A/C Compressor, you have to be prepared to replace additional components in the system depending on the reason why your own

compressor failed. The information provided below was made to help you save TIME and MONEY.

1.) Compressor locked/seized internally:

If your compressor seized internally it was due to insufficient refrigerant or oil in the system or the system was

blocked, leading to overheating of the compressor which caused a breakdown of internal parts.

Visible symptoms:

The oil in the compressor is black and/or has aluminum particles in it. The belt snapped or when the a/c is

turned on, the engine feels like it’s going to turn off.

What you should do:

1. Replace the A/C Compressor (make sure to add PAG Oil)

2. Replace the Receiver Drier/Accumulator

3. Replace the Expansion Valve/Orifice tube

4. Flushing the a/c lines, condenser and evaporator is REQUIRED (We professionally recommend to replace

the condenser on modern vehicles since the passage on the fins are so small that a flush will not remove all

contaminants).

5. Vacuum the system for 30 – 45 minutes. This will remove any moisture in the system.

6. Add the correct amount of refrigerant to the system.

7. Run vehicle on lowest fan setting for about 3 minutes to allow the compressor to cycle the refrigerant and oil.

The reason why it’s important to replace the additional parts listed is because if you add a

new compressor to acontaminated system, the compressor will cycle the contaminants and will eventually lock up again

2.) Compressor is making noise:

There are two possible reasons why your compressor is making noise.

First being that the compressor is suffering from internal damage due to a lack of refrigerant or oil in the system.This is an early sign that the compressor will seize,please go back to the first example and follow the instructions.The second reason is that thebearing on the compressor is bad.

Visible symptoms:

The compressor makes noise when the a/c is on or off, the clutch has a red/brown discoloration caused by overheating.

What you should do:

With the right tools and some mechanical knowledge,you can replace the bearing on the compressor without having to remove it from the vehicle.We carry almost all bearing sizes for a/c compressor clutches.

Please contact us and we will provide you with the item number so you may purchase the clutch bearing.

WNRLN Packing

ß ß ßWNRLN packaging and shock-proof foams, which have protective functions.

Their thickness is thicker than ordinary box and foam , Relatively speaking, the quality of WNRLN packaging is better than that of ordinary packaging.

ß ß ß It has the advantages of good stiffness and high wear resistance.

It is deeply loved by domestic and foreign customers.

Vehicle AC Compressor Problems vs. Low AC Refrigerant

Poor AC performance can often be traced back to either compressor failure or low AC refrigerant. Unfortunately, these vehicle components work hand-in-hand, making it hard to distinguish which is causing your AC troubles. So how can you tell if it is a compressor problem? There are a few subtle symptoms to look out for:

Freon Levels: If your AC system has optimal freon (refrigerant) levels (not too much or too little), but your air conditioner still does not work properly, this is often the sign of AC compressor failure.

Inconsistent AC Performance: Refrigerant leaks will only continue to get worse as the problem continues. On the other hand, a failing AC compressor might work well one day and poorly the next. While it is not applicable for all AC troubles, this symptom is an easy way to distinguish between low refrigerant and compressor problems.

Sudden AC Performance Drops: Refrigerant tends to leak gradually over time, while AC compressors can stop working on a dime. While even small refrigerant leaks can cause large AC problems, sudden drops tend to indicate compressor failure.

If you are still unsure of the source of your AC problems, it might be time to bring your vehicle to a mechanic for professional insight.
