Compressor 5801859861 Cooling AC Car For Fiat Ducato WXFT044

Compressor 5801859861 Cooling AC Car For Fiat Ducato WXFT044

Parameter:

Types of AC compressors for a car

There are various kinds of compressors in modern car air conditioning systems that are differing, for example, in power, performance, noise, etc. In general, we will consider some models of structures using the example of the  compressor range.

• The most popular type of compressor is a swashplate. The drum of the unit, containing several pistons (from five to seven), is driven by the engine of the car. The pistons circulate the refrigerant sliding relative to the stationary wobble plate. The volume of the pumped-over coolant can be changed due to the variable angle of inclination of the disc. compressors of this type (SE, SB, SL) are equipped with many large vehicles for which high performance of the AC system is important.

• Compressors with wobble plate, CA. In this design, on the other hand, the swashplate is movable, and the pistons and drum do not rotate. The distribution system in these compressors is a little more complicated, and today they are gradually losing ground.

• Scroll compressors are completely different types of AC compressors for a car. Their mechanism consists of two spirals: movable and fixed. Compressors of the SC type are renowned for their extremely low noise levels. Scroll compressors take up very little power from the engine and are therefore excellent for air conditioning systems in cars with small light engines. Due to its low energy consumption,  ES compressors with an electric drive are also equipped with a scroll mechanism. The advantage of these compressors is the ability to operate on the vehicle's battery, that is, with the engine off, which is important for hybrid vehicles.

• Finally, rotary vane compressors. These compressors are designed for low power systems. Their principle of operation is familiar to many motorists from booster pumps it is an eccentric in a chamber of variable volume, equipped with movable blades. The simplicity of the design of these compressors ensures their reliability and ease of maintenance.

What Does an Air Compressor in a Car Do?

Air compressors have made life easier for people on countless fronts since the early days of automotive assembly. One of the greatest innovations was Air Conditioning, which made life easier for people in the humid depths of summer months.

A/C systems were soon incorporated into automobiles, which allowed families to commute and embark on vacations in greater comfort because temperatures inside of passenger compartments could now be lowered by at least 20° from the outdoor weather. So what does a car’s air compressor do? The air compressor makes the whole A/C process possible in vehicles.
